Terminal Multiplexers: tmux and GNU Screen

A comprehensive guide to terminal multiplexing with tmux and GNU Screen, including advanced usage patterns, automation scripts, and practical workflows for system administrators and developers.

Overview

Terminal multiplexers are powerful tools that allow you to work with multiple terminal sessions within a single window. They are essential for remote server management, complex development workflows, and any scenario where you need to run multiple terminal commands simultaneously.

This guide covers two of the most popular terminal multiplexers:

1. tmux (Terminal Multiplexer) - A modern, feature-rich terminal multiplexer
2. GNU Screen - The classic terminal multiplexer with a long history

We'll also explore a specialized script called tmux-multiple that simplifies working with multiple synchronized sessions.

Basic Concepts

Sessions, Windows, and Panes

Both tmux and Screen organize your terminal workspace using a hierarchy:

• Sessions: Independent terminal instances that can be detached and reattached
• Windows: Virtual terminals within a session (like tabs in a browser)
• Panes: Split views within a window (horizontal or vertical divisions)

This organization allows you to:

• Run multiple commands simultaneously
• Monitor multiple processes
• Switch between different tasks easily
• Preserve your terminal state across network disconnections

tmux Basics

tmux Installation

# On Debian/Ubuntu
sudo apt install tmux

# On macOS with Homebrew
brew install tmux

# On CentOS/RHEL
sudo yum install tmux

Basic tmux Commands

| Command                      | Description                  |
|------------------------------|------------------------------|
| tmux                         | Start a new session          |
| tmux new -s name             | Start a new named session    |
| tmux ls                      | List all sessions            |
| tmux attach -t name          | Attach to a named session    |
| tmux detach (or Ctrl+b d)    | Detach from current session  |
| tmux kill-session -t name    | Kill a named session         |

tmux Key Bindings

All tmux commands are prefixed with Ctrl+b by default:

| Key Binding    | Action                                           |
|---------------|--------------------------------------------------|
| Ctrl+b c      | Create a new window                              |
| Ctrl+b n      | Move to the next window                          |
| Ctrl+b p      | Move to the previous window                      |
| Ctrl+b %      | Split the current pane vertically                |
| Ctrl+b "      | Split the current pane horizontally              |
| Ctrl+b arrow  | Navigate between panes                           |
| Ctrl+b z      | Toggle pane zoom (full-screen)                   |
| Ctrl+b [      | Enter copy mode (use vi or emacs keys to navigate) |

GNU Screen Basics

Screen Installation

# On Debian/Ubuntu
sudo apt install screen

# On macOS with Homebrew
brew install screen

# On CentOS/RHEL
sudo yum install screen

Basic Screen Commands

| Command              | Description                      |
|----------------------|----------------------------------|
| screen               | Start a new session              |
| screen -S name       | Start a new named session        |
| screen -ls           | List all sessions                |
| screen -r name       | Attach to a named session        |
| screen -d -r name    | Detach and reattach to a session |
| exit or Ctrl+d       | Exit the current screen          |

Screen Key Bindings

All Screen commands are prefixed with Ctrl+a by default:

| Key Binding    | Action                               |
|---------------|--------------------------------------|
| Ctrl+a c      | Create a new window                  |
| Ctrl+a n      | Move to the next window              |
| Ctrl+a p      | Move to the previous window          |
| Ctrl+a S      | Split the current region horizontally|
| Ctrl+a \|     | Split the current region vertically  |
| Ctrl+a tab    | Switch between regions               |
| Ctrl+a d      | Detach from the session              |
| Ctrl+a A      | Rename the current window            |

Advanced tmux Features

Synchronized Panes

One of the most powerful features of tmux is the ability to send the same commands to multiple panes simultaneously:

# While in tmux, toggle synchronization
Ctrl+b :setw synchronize-panes on
# To turn it off
Ctrl+b :setw synchronize-panes off

This is incredibly useful for:

• Managing multiple servers simultaneously
• Running the same commands on different environments
• Comparing outputs from different systems

Custom Configuration

Create a ~/.tmux.conf file to customize your tmux environment:

# Example tmux.conf
# Change the prefix key to Ctrl+a (like screen)
set -g prefix C-a
unbind C-b
bind C-a send-prefix

# Enable mouse mode
set -g mouse on

# Start window numbering at 1
set -g base-index 1

# Increase scrollback buffer size
set -g history-limit 10000

# Customize the status bar
set -g status-bg black
set -g status-fg white

Session Management

# Save tmux sessions using tmux-resurrect
Ctrl+b Ctrl+s  # Save
Ctrl+b Ctrl+r  # Restore

Advanced GNU Screen Features

Multiuser Sessions

Screen allows multiple users to share a session:

# Enable multiuser mode
Ctrl+a :multiuser on

# Grant permission to another user
Ctrl+a :acladd username

Screen Logging

# Start logging the current window
Ctrl+a H

Custom Configuration

Create a ~/.screenrc file to customize your Screen environment:

# Example screenrc
# Set a large scrollback buffer
defscrollback 10000

# Display a status bar
hardstatus alwayslastline
hardstatus string '%{= kG}[ %{G}%H %{g}][%= %{= kw}%?%-Lw%?%{r}(%{W}%n*%f%t%?(%u)%?%{r})%{w}%?%+Lw%?%?%= %{g}][%{B} %d/%m %{W}%c %{g}]'

# Skip the startup message
startup_message off

# Enable mouse scrolling
termcapinfo xterm* ti@:te@

tmux-multiple Script

The tmux-multiple script is a powerful tool for creating and managing multiple tmux panes with synchronized commands. It's especially useful for:

• Managing multiple servers
• Running the same command across different files
• Executing database queries across multiple databases

Script Overview

#!/bin/bash
# tmux-multiple
# Author: Mehmet Ali ERGUT
# https://github.com/memnuniyetsizim/tmux-multiple

This script simplifies creating multiple tmux panes and optionally synchronizing commands across them.

Usage

# Basic syntax
bash tmux-multiple.sh -t "SESSION_NAME" -c "COMMAND" -p "PARAM1;PARAM2;PARAM3"

# With synchronized panes
bash tmux-multiple.sh -g -t "SESSION_NAME" -c "COMMAND" -p "PARAM1;PARAM2;PARAM3"

Parameters

• -t: Session title/name
• -c: Command to run in each pane (optional)
• -p: Parameters separated by semicolons (one for each pane)
• -g: Enable synchronized panes (send commands to all panes)
• -i: Install the script with tmux configuration
• -h: Display help

Script Examples

Example 1: Edit multiple files simultaneously

bash tmux-multiple.sh -g -t "editConfig" -c "vim" -p "/etc/nginx/nginx.conf;/etc/hosts;/etc/ssh/sshd_config"

This creates a tmux session named "editConfig" with three panes, each running vim with a different configuration file. The -g flag enables synchronized panes, so your keystrokes are sent to all panes simultaneously.

Example 2: Monitor multiple log files

bash tmux-multiple.sh -t "logs" -c "tail -f" -p "/var/log/syslog;/var/log/auth.log;/var/log/nginx/error.log"

This creates a session with three panes, each tailing a different log file.

Example 3: Connect to multiple servers

bash tmux-multiple.sh -t "servers" -c "ssh" -p "user@server1;user@server2;user@server3"

This creates a session with three panes, each connecting to a different server.

How the Script Works

The script:

1. Creates a new tmux session with the specified name
2. Splits the window into multiple panes based on the parameters
3. Runs the specified command with each parameter in its respective pane
4. Arranges the panes in a tiled layout
5. Optionally enables synchronized input across all panes

Implementation Details

The core functionality relies on tmux's ability to create new panes and send commands:

# Create a new session
tmux new-session -d -s $sessionname

# For each parameter, create a new pane and run the command
for i in $parameters
do
    tmux split-window -v -t $sessionname "$runcommand $i"
    tmux select-layout tiled
done

# Enable or disable synchronized panes
if [ "$sync" != "" ]; then
    tmux set-window-option synchronize-panes on
else
    tmux set-window-option synchronize-panes off
fi

Compatibility Note

This script was developed for older versions of tmux and may require modifications for the latest versions. Key changes in newer tmux versions include:

• Mouse mode configuration changes
• Synchronize-panes syntax updates
• Window and pane indexing behavior

Implementing Similar Functionality with GNU Screen

While the tmux-multiple script is designed for tmux, similar functionality can be achieved with GNU Screen using a custom script:

#!/bin/bash
# screen-multiple.sh

usage() {
    echo "Usage: screen-multiple.sh -s SESSION_NAME -c COMMAND -p PARAM1,PARAM2,PARAM3"
    echo "  -s: Screen session name"
    echo "  -c: Command to run (optional)"
    echo "  -p: Parameters separated by commas"
    exit 1
}

# Parse arguments
while getopts "s:c:p:" opt; do
    case $opt in
        s) session=$OPTARG ;;
        c) command=$OPTARG ;;
        p) params=$OPTARG ;;
        *) usage ;;
    esac
done

# Check required parameters
if [ -z "$session" ] || [ -z "$params" ]; then
    usage
fi

# Create a new screen session
screen -dmS "$session"

# Convert comma-separated parameters to array
IFS=',' read -ra PARAM_ARRAY <<< "$params"

# For each parameter, create a new window and run the command
window=0
for param in "${PARAM_ARRAY[@]}"; do
    if [ -z "$command" ]; then
        screen -S "$session" -X screen $window "$param"
    else
        screen -S "$session" -X screen $window "$command $param"
    fi
    ((window++))
done

# Attach to the session
screen -r "$session"

Using the Screen Script

# Example: Edit multiple files
./screen-multiple.sh -s "config_edit" -c "vim" -p "/etc/hosts,/etc/nginx/nginx.conf,/etc/ssh/sshd_config"

# Example: Monitor logs
./screen-multiple.sh -s "logs" -c "tail -f" -p "/var/log/syslog,/var/log/auth.log,/var/log/nginx/error.log"

Practical Use Cases

Remote Server Management

Terminal multiplexers are invaluable for managing remote servers:

1. Persistent Sessions: Keep your work running even if your connection drops
2. Multiple Tasks: Monitor logs while editing configuration files
3. Synchronized Commands: Apply the same changes across multiple servers

Development Workflows

For developers, terminal multiplexers offer:

1. Split Workspace: Run your code in one pane, edit in another, and monitor output in a third
2. Multiple Services: Start database, backend, and frontend servers in separate panes
3. Testing: Run tests in one pane while coding in another

Database Administration

Database administrators can benefit from:

1. Multiple Connections: Connect to different databases simultaneously
2. Query Comparison: Run the same query against development and production
3. Monitoring: Watch logs and performance metrics while making changes

Performance and Resource Considerations

tmux vs Screen

| Feature         | tmux                   | GNU Screen                 |
|-----------------|------------------------|--------------------------|
| Memory Usage    | Generally lower        | Slightly higher           |
| CPU Usage       | Efficient              | Efficient                 |
| Feature Set     | More modern features   | More stable, fewer features |
| Customization   | Extensive              | Good                      |
| Scripting       | Excellent              | Good                      |
| Compatibility   | Newer systems          | Works on almost anything  |

When to Choose Each

• Choose tmux when:

  • You need advanced features like synchronized panes
  • You want a more modern, actively developed tool
  • You need better window/pane management

• Choose Screen when:

  • You need maximum compatibility with older systems
  • You prefer simplicity over features
  • You need multiuser capabilities

Best Practices

1. Use Named Sessions: Always name your sessions descriptively
2. Create Aliases: Set up aliases for common tmux/screen commands
3. Use Configuration Files: Customize your environment with .tmux.conf or .screenrc
4. Learn Key Bindings: Memorize the most common key combinations
5. Script Repetitive Tasks: Use scripts like tmux-multiple for common workflows

Conclusion

Terminal multiplexers like tmux and GNU Screen are essential tools for anyone who works extensively in the command line. They enhance productivity, enable complex workflows, and provide resilience against network disconnections.

The tmux-multiple script demonstrates how these tools can be extended and automated to handle even more complex scenarios. Whether you're managing multiple servers, working with various configuration files, or monitoring different processes, terminal multiplexers provide the flexibility and power you need.

By mastering these tools, you'll significantly improve your efficiency and capabilities in terminal environments.

References

1. tmux GitHub Repository
2. GNU Screen Manual
3. tmux-multiple Script
4. The Tao of tmux
5. Screen User's Manual
